REDARC BCDC Alpha100 R DC Battery Manager [A]

REDARC BCDC12100R Alpha 100A DC to DC Battery Charger

Overview

The REDARC BCDC12100R Alpha is a 12V, 100A DC to DC battery charger designed to deliver optimized multi-stage charging for auxiliary batteries using both alternator and compatible solar power. It automatically utilizes excess solar energy to top up the vehicle's start battery once the auxiliary battery is fully charged, maximizing available power.

Featuring Bluetooth connectivity for mobile monitoring, a Start Battery Recovery function, and a simple push-button interface, the BCDC12100R provides advanced battery management for RVs, 4WDs, overland vehicles, and off-grid applications.

Key Features

• 100A multi-stage DC to DC battery charger

• Combines alternator and compatible solar charging

• Automatically tops up the start battery using excess solar power

• Start Battery Recovery restores a flat start battery in as little as 15 minutes

• Bluetooth connectivity for mobile monitoring

• Monitor battery state of charge, remaining battery time, solar performance, charge current, and load current

• Push-button interface with screw terminal connections for straightforward installation

• Compatible with REDARC TVMS Rogue, TVMS Prime, and RedVision Bluetooth Display

Specifications

• Product: REDARC BCDC12100R Alpha DC to DC Battery Charger

• Model: BCDC12100R

• Nominal Output Voltage: 12V DC

• Charge Current: 100 A

• Charging Sources: Vehicle Alternator, Compatible Solar Panels

• Connectivity: Bluetooth

• Monitoring: Battery State of Charge, Battery Time Remaining, Solar Performance, Charge Current, Load Current

• Installation: Push-Button Interface with Screw Terminal Connections
