EWAVE Electric Outboard Motor for Boats

EWAVE 10 kW Electric Outboard Motor

Overview

Power your vessel with the EWAVE 10 kW Electric Outboard Motor, a compact, high-efficiency propulsion solution designed for small boats, tenders, and lightweight watercraft. Featuring a permanent magnet brushless DC (BLDC) motor, water-cooling system, and quiet electric operation, this outboard motor delivers smooth, responsive performance without emissions.

Engineered for easy integration, the EWAVE Electric Outboard Motor is suitable for new boat builds and gasoline outboard conversions, providing reliable electric propulsion for a wide range of marine applications.

Key Features

• 10 kW electric outboard motor with permanent magnet BLDC technology

• High-efficiency brushless DC motor

• Closed-loop water cooling system

• Maximum motor speed of 7,000 RPM

• Steering handle with integrated throttle and gear control

• Stepless variable speed with forward and reverse gears

• Electric switch start

• Manual tilt system for lifting and launching

• 9-inch propeller

• Quiet, zero-emission electric propulsion

• Designed for easy installation and integration

Ideal Applications

• Small electric boats

• Boat builder projects

• Tender boats

• Dinghies

• Rescue boats

• Leisure craft

• Gasoline outboard motor conversions

Specifications

• Rated Power: 10 kW

• Motor Type: Permanent Magnet Brushless DC (BLDC)

• Cooling System: Water cooling

• Maximum Motor Speed: 7,000 RPM

• Control System: Manipulator handle

• Starting System: Electric switch start

• Gear System: Stepless variable speed (forward and reverse)

• Tilt System: Manual tilt

• Propeller Size: 9 in (23 mm)

• Top Speed: Up to 30 km/h (with 200 kg load)

• Rated Voltage: 48 V

• Recommended Battery: Greater than 200 Ah

• Net Weight: 25 kg

• Dimensions: 2700 × 1050 × 850 mm
