REDARC BCDC2420 24V 20A DC to DC Battery Charger

Overview

The REDARC BCDC2420 is a 24V, 20A, 3-stage DC to DC battery charger designed for 24V automotive systems with an input voltage range of 9-32V DC. Engineered for demanding vehicle applications, including trucking, it efficiently charges auxiliary battery banks while driving and is well suited for powering equipment such as tailgate lifters and side curtains.

Featuring an integrated MPPT Solar Regulator, the BCDC2420 can utilize compatible 12V solar panels to charge 24V auxiliary batteries. Its compact, fully sealed construction protects against dust, water, vibration, and high operating temperatures for reliable performance in harsh environments.

Key Features

• 24V, 20A, 3-stage DC to DC battery charger

• Integrated MPPT Solar Regulator

• Compatible with 12V solar panels for charging 24V auxiliary batteries

• Operates with an input voltage range of 9-32V DC

• Fully sealed construction resists dust, water, and vibration

• Designed for trucking, automotive, and heavy-duty vehicle applications

• Operates in temperatures up to 176°F (80°C)

• Compatible with AGM, Gel, Calcium, VRLA, and Standard Lead Acid batteries

Specifications

• Product: REDARC BCDC2420 DC to DC Battery Charger

• Model: BCDC2420

• Charge Current: 20 A

• Nominal Output Voltage: 24V DC

• Charging Stages: 3-Stage

• Input Voltage Range: 9-32V DC

• Integrated Solar Regulator: MPPT

• Solar Panel Compatibility: 12V Solar Panels

• Maximum Operating Temperature: 176°F (80°C)

• Compatible Battery Types: AGM, Gel, Calcium, VRLA, Standard Lead Acid

• Construction: Fully Sealed
